Our HDMI AOC (Active Optical Hybrid Cable) is the most competitive long reach HDMI interconnection solution on the market. It supports HDMI Maximum Data Rate 18Gbps with light weight, flexible, making it easy to install in conduit. With our advanced optical engine embedded chipset, this HDMI Hybrid Cable provides full HDMI signal integrity, support up to 100m (328ft) maximum length. No external power required.
Advanced leading edge technology makes use of 4 glass fibers and 7 copper wires to provide the necessary power to the embedded micro-chips at the transmit (TX) and receiving (RX) end of the cable. All the advanced features you need for today and tomorrows 4K audio and video! HDMI 2.0 / HDCP 2.2 verified by Quantum Data, and authorized HDMI LLC testing facility. This is a UNI-DIRECTIONAL cable - it must be installed with the DISPLAY connector to the display, and the SOURCE connector to the source equipment to function properly.

Technical Specifications

Features and Specifications

● 4K x 2K 60Hz/fps YUV 4:4:4 at 8bit (18Gbps) Support

● Full 3D Support, HDCP 2.2 support

● Maximum bend radius: 52mm

● Detachable HDMI Type-A Ends to facilitate conduit installation

● Patented locking HDMI end connectors

● Meets HDMI 2.0 testing standards (results independently certified by Murideo and Quantumn Data)

● HEAC support (HDMI Ethernet), ARC (Audio Return Channel), HDR (High Dynamic Range) Support

● Independently tested (Radiated Emission Test) to meet FCC standards from 30-1000Mhz. Testing documents available upon request.

● Durable Zinc Alloy Shells

● EMI/RFI Resistant

● Cable Outer Diameter: 4.5mm

● Cable Spec: Fiber Optic (50/125um multimode) / Copper (28AWG) Hybrid

● Jacket: TPE/LSZH (Low Smoke Zero Halogen)
